In 4-channel mode, its CEA power of 4 x 70W RMS will allow you to get the most from your Auditor kits installed up front and in the rear. The 3-channel mode enables you connect a kit to channels one and two, as well as an Auditor subwoofer to channels three and four in bridged mode for a CEA power of 190W RMS under 2 Ohms. The 2-channel mode, which consists of bridging channels 1-2 and 3-4, provides a CEA power of 2 x 190W RMS under 2 Ohms.

Equipped with high-pass and low-pass crossovers, as well as a subsonic crossover, the AP-4340 amplifier guarantees the optimal performance of the kits and subwoofers in this line.

Specifications

• Good power/quality ratio
• Bridgeable
• Stable under 2Ω 4/3/2-channel A/B class amplifier
• CEA power (4Ω) 4x70W RMS
• Max. power (2Ω) 4x95W
• Max. power (4Ω bridged) 2x190W
• Bandwidth (-3dB) 10Hz - 30kHz
• THD 0,06%
• Channel separation (1 KHz) 45 dB
• SNR (1W/A) 76 dBA
• Low level input sensitivity 160mV
• High-pass crossover (channel 1-2) 60Hz to 1.2kHz
• Low-pass crossover (channel 3-4) 50 to 250Hz
• Full-Range mode Yes
• Dimension (Lxlxh) 1325/64x131/32x91/43" (340x50x235mm)
• Weight 2.75kg 6.06lbs
• Protections Short-circuit / Low impedance / DC Polarity reversal Thermal over / under voltage
