Hertz Compact Power HCP 1DK
Κωδικός : 02.02.0002
396,00 €
Άμεσα διαθέσιμο
| Channels | 1 |
| POWER SUPPLY | |
| Power supply voltage / fuse: | 11 ÷ 15 VDC / 3 x 30 A |
| Idling current (power ON/OFF): | 0.8 A / 1 mA |
| Consumption @ 2 Ω, 14.4 VDC (Max Musical Power): |
45 A |
| Remote In: | 7 ÷ 15 VDC - 1 mA |
| ART: | Automatic Remote Turn-On/Off with Speaker-In |
| AMPLIFIER STAGE | |
| Distorsion - THD (100 Hz @ 4 Ω) | 0.25 % |
| Bandwidth: | 10 ÷ 500 Hz |
| S/N Ratio (A weighted @ 1 V): | 100 dB |
| Damping factor (100 Hz @ 4 Ω): | > 100 |
| Pre-In sensitivity: | 0.2 ÷ 5 VRMS |
| Speaker-In sensitivity: | 0.8 ÷ 20 VRMS |
| Load impedance (MIN): | 2 Ω |
| Max size (mm / in.): | 315 x 190 x 50 / 12.40 x 7.48 x 1.97 |
| Weight (kg / lb.): | |
| Adjustable Crossovers | yes |
| Output Power (RMS) @ 14.4 VDC, THD 1% | |
| 1 Ch: | 740 W x 1 (4 Ω) |
| 1 Ch: | 1240 W x 1 (2 Ω) |
| CEA 2006-A Ratings: | |
| RMS Power (4Ω, ≤1 % THD + N, 14.4 V): |
600 W x 1 Ch |
| S/N Ratio (ref. 1 W output): | 80 dBA |
| Total Power RMS | 2480 W |
