Ενισχυτής Marine – Hertz HCP 4M
Κωδικός : 19.0004
355,00 €
319,00 €
-10%
Άμεσα διαθέσιμο
| Channels | 4 - 3 - 2 |
| POWER SUPPLY | |
| Power supply voltage / fuse: | 11 ÷ 15 VDC / 2 x 20 A |
| ldling current (power ON/OFF): | 1 A / 0.04 mA |
| Consumption@ 1Ω, 14.4 VDC (Max Musical Power): | 21 A |
| Remote In: | 7 ÷ 15 VDC - 1 mA |
| ART: | Automatic Remote Turn-OniOff with Speaker-ln |
| AMPLIFIER STAGE | |
| Distorsion - TliD (100Hz @ 4Ω): | 0.01% |
| Bandwidth: | 10 ÷ 45 kHz |
| S/N Ratlo (A welghted @ 1 V): | 103 dB |
| Damping factor (100Hz @ 4Ω) | 120 |
| Pre-ln sensitivity: |
0.2 ÷ 5 VRMS |
| Speaker-ln sensitivity: | 0.8 ÷ 20 VRMS |
| Load impedance (MIN) @4Ch: @3Ch: @2Ch: |
2 Ω + 2 Ω + 4 Ω 2 Ω 4 Ω |
| Max size (mm/in): | 315 x 190 x 50 / 12.40 x 7.48 x 1.97 |
| Weight (kg/lb): | 2.62 / 5.77 |
| Adjustable Crossovers | yes |
| OUTPUT POWER (RMS) @ 14.4 VDC, THD 1% | |
| 4Ch |
55 W x 4 (4Ω) |
| 4Ch |
85 W x 4 (2Ω) |
| 3Ch |
55 W x 2 (4Ω) + 170 W x 1 (4Ω) |
| 3Ch |
85 W x 2 (2Ω) + 170 W x 1 (4Ω) |
| 2Ch |
170 W x 2 (4Ω) |
| OUTPUT POWER (RMS) @ 14.4 VDC, THD 10% | |
| 4Ch |
65 W x 4 (4Ω) |
| 4Ch |
95 W x 4 (2Ω) |
| 3Ch |
65 W x 2 (4Ω) + 190 W x 1 (4Ω) |
| 3Ch |
95 W x 2 (2Ω) + 190 W x 1 (4Ω) |
| 2Ch |
190 W x 2 (4Ω) |
| CEA 2006-A RATINGS | |
| RMS Power (4 Ω, ≤ 1 % THD+N,14.4 V): |
50 W x 4 Ch |
| S/N Ratio (ref. 1 W output) | 82 dBA |
| Total Power RMS | 760 W |
| lnputs: | PRE IN / SPEAKER IN |
| Pre Out FULL range (FRONT) | Yes |
| FRONT Ch. filters FULL: | Yes |
| Hi-Pass: | 80 Hz @ 12 dB/Oct |
| Lo-Pass: | 50 ÷ 500 Hz @ 12 dB/Oct |
| REAR Ch. filters FULL: |
Yes |
| Hi-Pass: | 80 Hz @ 12 dB/Oct |
| Lo-Pass: | 50 ÷ 500 Hz @ 12 dB/Oct |
| FRONT Ch. MONO (on/off): | Yes |
| REAR Ch. MONO (on/off): | Yes |
| BOOST 50 Hz (adjust): | (0 / 6 / 12) dB |
| mm | in | |
| A | 315 | 12.40 |
| B | 291 | 11.45 |
| C | 190 | 7.48 |
| D | 166 | 6.53 |
| E | 50 | 1.97 |
